Data Input Area

Non-integer values must be separated by a dot.


mm
mm
mm
pcs
mm
mm
pcs

Values marked with * are mandatory to fill in.

All calculated data is for informational purposes only.

F¹=572.16
F²=1144.31
F³=1945.34
L0=120
L¹=100
L²=80
L³=52.00
D(inner)=48.00
D(outer)=64
t=13.50
d=8
Material: GOST 9389-75 B-2
My weight: 0.69348 kg.
Spring Calculation
Support Turns Option Compressed, polished
Average Diameter (D avg.) 56.00 mm
Inner Diameter (D inner) 48.00 mm
Free Height (L0) 120 mm
Total Number of Turns (n1) 10.00 pcs
Preload (F¹) 572.16 N
Working Load (F²) 1144.31 N
Maximum Load (F³) 1945.34 N
Length at Coil Contact (L³) 52.00 mm
Spring Stiffness (c) 28.61 N/mm
Step (t) 13.50 mm
Unwinding of the Spring 1758.40 mm
Spring Mass (m1) 0.69348 kg
Batch Weight (m2) 1248.27 kg
